Molift Air 200

The compact, powerful hoist, optimized for most day-to-day hoisting needs (SWL 205 kg)

Molift Air 200 is the smallest member of the Molift Air family. Combined with the Molift Rail System and Molift slings, Molift Air solves most day-to-day hoisting situations in health care and other patient handling environments.

Comfort and quality
Molift Air 200 combines the need for maximum comfort with efficient and safe hoisting situations. The design and user-friendliness bring exceptional freedom, which enables a single caregiver to perform daily lifting situations, allowing more time for caring for the individual user. For the caregiver, a better working environment is possible without the need for manual lifting. The user experiences a dignified, safe and comfortable lifting.

The flexible hoist
Molift Air 200 is suitable for sitting and horizontal transfers, as well as standing and gait training situations. It is used with fixed ceiling rails but can also be used for portable free-standing systems.

Molift Air 200 is easy to handle during installation and servicing, due to its very low weight and clever quick-release function.

Molift Air 200 offers flexible solutions such as In-Rail Charging (IRC), Propulsion and possibilities for room-to-room transfer. Add to this the safety features, the large lifting interval and the multiple range of sling bars. This hoist is the complete solution for all healthcare segments.

Molift Rail System

The Molift Rail System enables dignified care for patients and a healthy and efficient work environment for healthcare staff in hospitals, institutions and home care. Read about a versatile, cost-effective and efficient ceiling hoist solution.

Transfer users seamlessly between rooms

Since intruding into the doorframe's physical structure is not always possible, room-to-room functionality is ideal when users must be transferred between two rail systems in adjoining rooms.

Molift Service Tool on laptop_800x450.jpg

Molift Service Tool - an intelligent software

All Molift hoists are supplied with the Molift Service Tool – an intelligent software that interacts with the hoist, ensures correct service and maintenance, and enables analysis of the lift's use.

Features

Small hoist - great lifting capacity

Molift Air 200 is very small and weighs only 8.6 kg. Nevertheless it has a lifting capacity (SWL) of 205 kg. The size and weight makes it very easy for the carer to operate and move during different transfer situations.

Quick release device for trolley

Molift Air 200 is easy to handle during installation and servicing, due to a very low weight and the clever quick release function. With a simple grip, the motor is disconnected from its trolley and removed.

Silent and soft operation

Molift Air works very quietly and has a soft start and stop operation. This results in a comfortable and safe feeling for the user during the transfer situation.

Intuitive hand control

Molift Air 200 has an intuitive hand control with a hanger on the sling bar and an optional docking station or parking bracket for the wall.

Variants and details

Specifications for all variants
Battery charge time (hours)	6	Material	Aluminium, plastic
Expected lifetime	30,000 lifts SWL/10 years	Protection class	IP24
Height (mm)	195	Safe working load (SWL) (kg)	205
Hoisting speed 75 kg (mm/sec)	60	Weight (kg)	8.6
Length (mm)	360	Width (mm)	190

	Item number	Battery	Battery charger	Hoisting interval (mm)
Molift Air 200 - Li battery	M26201	25,6 V LiFePO4 2,4 Ah	100–240 V AC, 40–60 Hz	3000
Molift Air 200 - SLA battery	M26200	12 V SLA 2,9 Ah	100–240 V AC, 40–60 Hz	3000
Molift Air 200 IRC	M26356	12 V SLA 2.9 Ah	100-240 V AC, 50-60 Hz max 0.5A	2600
Molift Air 200 IRC Propulsion	M26358	12 V SLA 2.9 Ah	100-240 V AC, 50-60 Hz max 0.5A	2600
Molift Air 200 Propulsion	M26359	12 V SLA 2.9 Ah	100-240 V AC, 50-60 Hz max 0.5A	2600

Documents

Download of user manuals are intended for expedient purpose only. The products in reference may be subject to change without prior notice and reader’s discretion is advised to ensure coherence with product version and article number as well as the appropriate translation.
