R82 Mustang

The R82 Mustang offers an individual solution in children's walking aids and is thoughtfully designed to potentially enhance mobility for children with a range of needs. Its design emphasizes not only function but also aesthetics. This children's walking frame is designed to help children with cerebral palsy and other children with impairments of their motor function.

The Mustang provides excellent and snug support for the upper body whilst also keeping the child’s pelvis gently supported. The upright, slightly forward leaning position stimulates the walking function and encourages the child to participate in daily activities.

The Mustang can be used by children with cerebral palsy and others with impairments of their motor function. The Mustang is developed as an anterior walker but can also be used as a posterior gait trainer, depending on the child’s level of ability.

The Mustang is available in four sizes and suitable for children and young people.

Discover

Tommy achieves encouraging gait progress with R82’s Mustang

Read about how the Mustang helped Tommy in his gait progress.

Features

Motivating the child to walk

The user is placed at the centre of the Mustang which provides core stability and enables the user to focus energy on walking.

Natural walking pattern

The Mustang has an easy to adjust central bar for height and angle adjustments. A slight forward leaning position, combined with built-in suspension, stimulates the natural walking pattern.

Easy to access

The Mustang has been constructed with accessibility in mind. The U-shaped frame and wrap around support, allows for easy access and transfer.

Easy changeable accessories

Accessories are easily added or removed for the carers' convenience.

Variants and details

	Size 1	Size 2	Size 3	Size 4
Item number	869011	869024	869033	869042
Angle, center bar (°)	30	30	25	25
Height with 4" wheels (mm)	400-650	600-850	-	-
Height with 8" wheels (mm)	510-650	600-850	700-1050	1030-1250
Inside width (mm)	380	450	500	560
Length with 4" wheels (mm)	750	830	-	-
Length with 8 " Wheels (mm)	820	900	1000	1100
Mass device with 4" wheels (kg)	10	11	-	-
Mass device with 8" wheels (kg)	13	14	18	19
Maximum rated load (kg)	45	56	80	101
Maximum user mass (kg)	30	40	60	80
Minimum turning radius (mm)	360	550	600	650
Overall width with 4" or 8" wheels (mm)	520	580	650	700
Seat height with 4" wheels (Comfort seat) (mm)	170-430	240-490	-	-
Seat height with 4" wheels (PU seat) (mm)	170-350	240-410	-	-
Seat height with 8" wheels (Comfort seat) (mm)	260-520	330-580	450-760	620-920
Seat height with 8" wheels (PU seat) (mm)	260-440	330-500	450-680	620-840
Static stability downhill (°)	7	7	7	7
Static stability sideways (°)	4.5	4.5	4.5	4.5
Static stability uphill (°)	15	15	15	15
User height: floor to axil (mm)	400-650	600-850	700-1050	870-1300
Width between handles (mm)	165-320	165-320	140-400	140-400

Options

Frame colour

Available in 4 colours.

Yellow for size 1

White for size 2

Red for size 3

Anthracite grey for size 4

Castors and wheels

The Mustang is delivered as standard with various wheel options. Choose between the below options.

4" castor for size 1 and 2

8" slimline wheel

Wheel features

Unique features and adjustment possibilities.

Directional stabilizer

Tension adjustable wheels

Brake on all 4 wheels

Anti-reverse wheel stop - release

Anti-reverse wheel stop - lock

Documents

Download of user manuals are intended for expedient purpose only. The products in reference may be subject to change without prior notice and reader’s discretion is advised to ensure coherence with product version and article number as well as the appropriate translation.
