R82 Caribou
The Caribou is a versatile paediatric standing aid that supports prone, upright, or supine standing positions. The Caribou is an ideal solution for children who have limited head and trunk control, or limited range of motion.
The Caribou's tilt function and extensive accessory selection make it an excellent choice for children with disabilities. It is available in four sizes and can accommodate children from approximately 850 mm to 1840 mm in height, with a maximum user mass of 100 kg. Whether you need a prone stander or a supine stander the Caribou is a suitable choice.
The Caribou helps children build strength, improve their posture, and participate in activities with their peers. With its various sizes and options, the Caribou is a versatile standing frame that can grow with your child and adapt to their changing needs.
In summary, the R82 Caribou is an excellent standing frame for children with disabilities. Its versatile design, tilt function, and extensive accessory selection make it an excellent choice for parents and caregivers looking for a paediatric stander that can help their child stand and participate in activities they love.
Features
Anatomic design and soft mouldable PU
Easy transfer
Interchangeable accessories
Easy tilt
Variants and details
| Size 1 | Size 1 (w/ power) | Caribou Size 2 | Size 2 (w/ power) | Caribou Size 3 | Size 3 (w/ power) | Caribou Size 4 | Size 4 (w/ power) | |
|---|---|---|---|---|---|---|---|---|
| Item number | 860101 | 860101-EL | 860102 | 860102-EL | 860113 | 860103-EL | 860114 | 860104-EL |
| Angling (°) | 0-87 | 0-87 | 0-87 | 0-87 | 0-87 | 0-87 | 0-87 | 0-87 |
| Approximate total user height (mm) | 850-1120 | 850-1120 | 980-1290 | 980-1290 | 1250-1560 | 1250-1560 | 1530-1840 | 1530-1840 |
| Foot plate angle (°) | (-20) - 20 | (-20) - 20 | (-20) - 20 | (-20) - 20 | (-20) - 20 | (-20) - 20 | (-20) - 20 | (-20) - 20 |
| Length (mm) | 750 | 750 | 920 | 920 | 1110 | 1110 | 1110 | 1110 |
| Maximum rated load (kg) | 62.5 | 64.5 | 86 | 87.5 | 112.5 | 114.5 | 137 | 139 |
| Maximum user mass (kg) | 40 | 40 | 60 | 60 | 80 | 80 | 100 | 100 |
| Overall height, horizontal (mm) | 700 | 700 | 700 | 700 | 800 | 800 | 800 | 800 |
| Overall height, vertical (mm) | 460-570 | 460-570 | 530-640 | 530-640 | 680-790 | 680-790 | 880-990 | 880-990 |
| Overall width (mm) | 510 | 510 | 570 | 570 | 650 | 650 | 750 | 750 |
| Static stability downhill (°) | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 |
| Static stability sideways (°) | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 |
| Static stability uphill (°) | 5 | 5 | 5 | 5 | 5 | 5 | 5 | 5 |
| Total mass (kg) | 20.5 | 22.5 | 24 | 25.5 | 30.5 | 32.5 | 35 | 37 |
Overall height configuration: Standard product and top plate (measured from the floor)
Washing instructions
Options
Frame colour
Available in different colours.
Red for size 2
Blue for size 3
Anthracite grey for size 4
Foot plates
Parted foot supports makes it possible to adjust individual foot heights and angles.
Tilt mechanism
Goes from minus 3 degrees to horizintal position. Sizes 3 and 4 are recommended in the power versions to ease tilting.
Foot operated gas spring
With power actuator
Accessories
Documents
Download of user manuals are intended for expedient purpose only. The products in reference may be subject to change without prior notice and reader’s discretion is advised to ensure coherence with product version and article number as well as the appropriate translation.
Videos
How to mount the tray top cover
