Floor frame
Floor Frame is a frame supporting early intervention through the option of supported floor sitting. Sitting at floor level can support playful activities with family, siblings and friends and facilitate meaningful tasks with arms and hands such as reaching and grasping for toys. The frame has 5 options of leg positions when the short legs are mounted – both for the front legs and the back legs. The 5 different positions enables 4 different seat to floor heights, when the seat is level, and a variety of tilt angles to accommodate different leg lengths and playful activities. A set of four long legs are also available with the floor frame.
Features
Easy to transport
Low floor to seat height
Long legs
Tilt options
Variants and details
| One size | |
|---|---|
| Item number | 821111 |
| Compatible with | x:panda shape infant and size 1, x:panda size 1 and 2 |
| Folded height (mm) | 60 |
| Folded length w/o legs (mm) | 378 |
| Folded width w/o legs (mm) | 369 |
| Mass device (kg) | 3 |
| Mass device (lbs) | 6.6 |
| Max load (kg) | 43.5 |
| Maximum rated load (kg) | 50 |
| Overall height, floor to top of frame (mm) | 60 – 192 |
| Overall height, floor to top of frame w/ long legs (mm) | 450 |
| Overall length (mm) | 335 – 525 |
| Overall length w/ long legs (mm) | 505 |
| Overall width (mm) | 396 |
| Overall width w/ long legs (mm) | 522 |
| Seat plane angle (°) | (-25°) – (25°) |
| Seat surface height at front edge (mm) | 7 – 12 |
| Seat surface height at front edge w/ long legs (mm) | 570 |
| Seat surface to foot support (mm) | 183 – 274 |
| Static stability downhill (°) | 5 |
| Static stability sideways (°) | 5 |
| Static stability uphill (°) | 5 |
Documents
Download of user manuals are intended for expedient purpose only. The products in reference may be subject to change without prior notice and reader’s discretion is advised to ensure coherence with product version and article number as well as the appropriate translation.
