R82 Swan Curo

The R82 Swan Curo is a toilet and bath chair developed for children and youngsters with special needs.

The Swan Curo toilet and bath chair has a minimalistic design and a small footprint, making it suitable for various bathrooms and homes. The shell is perfectly shaped for high comfort and with smooth surfaces for easy cleaning. The PU inlay is soft and ensures optimal seating comfort for the user and is easy to attach and detach. The gas spring-supported tilt mechanism comes as standard and makes the chair easy to adjust during use. The frame is height-adjustable to accommodate a wide range of toilets.

The Swan Curo is available in 4 different sizes. Size 1 is available with and without castors. Size 2-4 comes with castors.

Features

Versatile functionality

The R82 Swan Curo is a multifaceted toilet and bath chair, ideal for various daily self-care and wellness activities. This allows the child to be as active and involved as possible, promoting quality of life, minimising the need for transfers and the physical workload for the caregiver.

Everyday convenience

Due to a minimalist and small footprint of the frame the toilet and bath chair fits very well into various houses and bathrooms. The simple design makes the chair very user-friendly and lightweight – making it easy for the caregiver to handle and the smooth surfaces easy to clean.

Comfort & support

The shell is carefully designed to enclose the user, which along with the soft PU inlay, ensures high seating comfort. The PU inlay is easy to attach and has high durability. Head support, vests and belts ensure ideal support for the user.

Individual adjustment

Positioning of the user is easily done using the tilt function assisted by a gas spring and the height- and angle-adjustable foot support. To obtain the best possible height for transfer, for caregivers or the toilet, the frame is height-adjustable.

Variants and details

	Size 1 without castors	Size 1	Size 2	Size 3	Size 4
Item number	87060	87061	87062	87063	87064
Aperture W x D (mm)	125x185	125x185	150x220	180x280	180x330
Aperture with inlay W x D (mm)	100x175	100x175	125x210	155x270	155x320
Back width, bottom of backrest (mm)	210	210	250	315	400
Back width, top of backrest (mm)	270	270	350	425	490
Backrest height (mm)	380	380	470	525	600
Effective seat depth (mm)	265	265	310	400	450
Effective seat width (mm)	220	220	260	320	410
Length, with castors outside (low/high) at 0° tilt (mm)	-	495/555	625/645	680/715	680/715
Length, without castors outside (low/high) at 0° tilt (mm)	400/425	-	-	-	-
Mass device, with castors (kg)	-	8.5	10.5	11.75	12.75
Mass device, without castors (kg)	7.5	-	-	-	-
Maximum rated load with castors (kg)	-	46	73	99	125
Maximum rated load without castors (kg)	45	-	-	-	-
Maximum user mass (kg)	35	35	60	85	110
Minimum distance for turning 180° allowing for reversing movement (mm)	705	705	820	895	945
Minimum distance for turning 180° forward in movement (mm)	1205	1205	1350	1475	1600
Minimum turning diameter (mm)	1410	1410	1640	1790	1890
Overall height with castors (mm)	-	760-920	960-1120	990-1150	1060-1220
Overall height without castors (mm)	670-830	-	-	-	-
Overall width with castors (mm)	-	500	530	580	655
Overall width without castors (mm)	460	-	-	-	-
Pelvis width (mm)	240	240	275	340	420
Seat plane angle (°)	0°- 20°	0°-20°	0°-20°	0°- 20°	0°- 18,5°
Seat surface height at front edge, with castors (mm)	-	380-540	480-640	470-630	465-625
Seat surface height at front edge, without castors (mm)	290-450	-	-	-	-
Seat width front (mm)	320	320	355	425	475

Cleaning instructions: The product can be washed at 60 °C / 140 °F for 10 minutes and at 85 °C / 185 °F for 3 minutes in a washing machine for medical devices. Disinfect with a 70% disinfectant IPA solution. Use warm water and mild detergent without chlorine for cleaning.

Options

Castors

Size 1 is available with and without castors. Size 2-4 comes with castors.

Without castors (only for size 1)

With castors

Accessories

29 results found

Cushions & covers

Documents

Download of user manuals are intended for expedient purpose only. The products in reference may be subject to change without prior notice and reader’s discretion is advised to ensure coherence with product version and article number as well as the appropriate translation.
